The correct use of machinery and equipment, careful implementation of maintenance and upkeep regulations, and strict adherence to safety operating procedures are necessary conditions to ensure the safe production of equipment and improve production efficiency. The maintenance summary for the gantry shear machine is as follows:
Precautions for weekly maintenance of gantry shear machine:
1. Check the oil filter and clean it if necessary.
2. Check whether the positions of the oil pump, valve, and oil cylinder are correct, and adjust them in a timely manner if there is displacement.
3. Check whether all important connecting bolts are securely fastened, and tighten them if they are loose. For example, the connection between the cutting frame and the material box, the connection between the scissor slider, the pressing block, the feeding slider and the piston rod, the connection between the flange of each cylinder port and the cylinder bottom and the cylinder body, and the connection between the left and right guide rails and the frame.
4. Lubricate each part of the shear machine according to the different requirements of each model.
Precautions for annual maintenance of gantry shear machine:
1. Add new lubricants to the motor rotor bearings according to the requirements of different models.
2. Check the degree of contamination and wear resistance of hydraulic oil.
3. Clean the air filter on the main oil tank and add hydraulic oil.
4. Check the oil filter and observe the sediment in it. If there are many black objects, it indicates that dust has entered. Check the seals of each oil cylinder and replace them if necessary.
Lubrication and maintenance of gantry shear machine:
For the lubrication work of gantry shear machines, enterprises must pay attention to it. Lubrication can reduce the wear rate of vulnerable parts. There are different requirements for lubrication of different models of shear machines, and operators should choose according to the manufacturer's requirements. Each lubrication point of the machine should be filled with lubricating oil as required.
